#include <stm32f10x_lib.h>
#include "sys.h"
#include "delay.h"
#include "usart.h"
#include "led.h"
int main(void)
{
u8 k; //點亮的燈位數
u8 i;
Stm32_Clock_Init(9); //系統時鐘初始化
delay_init(72); //延時初始化
uart_init(72,9600); //串口初始化
led_init(); //燈I/O配置初始化
while(1)
{
if(USART_RX_STA&0x80) //接受到數據判斷
{
printf("\n you send massage is :\n");
for(i=0;i<(USART_RX_STA&0x3f);i++)
{
USART1->DR=USART_RX_BUF[i]; //把接受到的數據傳給電腦
k=USART_RX_BUF[2]-0x30; //接受到要開發的燈泡值
}
USART_RX_STA=0; //接受位清零
}
if(k==1)LED1=0; //判斷點亮那個燈
if(k==2)LED2=0;
if(k==3)LED3=0;
if(k==4)LED4=0;
if(k==5)LED5=0;
if(k==6)LED6=0;
if(k==7)LED7=0;
if(k==8)LED8=0;
}
}
//-------------------------------------燈配置庫函數---------------
//-------------------------------------燈配置庫函數---------------
#include <stm32f10x_lib.h>
#include "led.h"
void led_init()
{
RCC->APB2ENR|=1<<3; //時能PORTB時鐘
GPIOB->CRL&=0x00000000; //清空寄存器值
GPIOB->CRL|=0x33333333; //推挽輸出
GPIOB->ODR=0xffff;
}
#ifndef _led_h
#define _led_h
void led_init(void);
#define LED1 PBout(0)
#define LED2 PBout(1)
#define LED3 PBout(2)
#define LED4 PBout(3)
#define LED5 PBout(4)
#define LED6 PBout(5)
#define LED7 PBout(6)
#define LED8 PBout(7)
#endif
